Price Pump 2in Non-Metallic Bolted Air Operated Diaphragm Pump

170 GPM maximum flow, heads to 270ft.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our pump experts at 1-802-255-4003. We’re open Mo-Fr 8:30am to 5:00pm ET.
Starting Price: $5,366.00
Selected Options: + ${{ calcAdditionalCost | formatCurrency }}
Request pricing below.
${{ calcCost | formatCurrency }} ${{ (calcCost * calcQuantity) | formatCurrency }} per {{ calcQuantity }} (${{ (calcCost * boxQuantity) | formatCurrency }} per {{ boxQuantity }}) ${{ calcCost | formatCurrency }}
Configured Part No. {{ calcPartNumber }}
{{ calcAvailability }}
Alternate Part Nos. {{pn}}
{{pn}}
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo
Product Specs
Highlights...

Features

  • 125 PSI maximum air inlet pressure
  • 2 ANSI flange/DIN suction (bottom)
  • 2 ANSI flange/DIN discharge (top)
  • Neoprene, Buna-N, Santoprene, EPR, Viton, and Teflon elastomers
  • Polypropylene or Kynar (PVDF)l pump material

The Price Pump 2in Non-Metallic Bolted Air Operated Diaphragm Pump is designed for non-metallic fluid handling applications across industries including chemical, automotive, marine, and manufacturing sectors.

The pump's "posi-shift" tandem spool air distribution valve ensures stall-free operation in low-pressure and intermittent applications while eliminating the need for oil lubrication. This oil-less design prevents environmental contamination and reduces maintenance costs by eliminating metal-to-metal wear surfaces. The externally serviceable air valve allows for routine maintenance without pump disassembly, minimizing downtime.
