American-Marsh TWU Series Dewatering Pump

4-inch submersible well pump with Noryl impellers, 5 to 80 GPM flow rates, vertical or horizontal installation.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our pump experts at 1-802-255-4003. We’re open Mo-Fr 8:30am to 5:00pm ET.
Request pricing below.
${{ calcCost | formatCurrency }} ${{ (calcCost * calcQuantity) | formatCurrency }} per {{ calcQuantity }} (${{ (calcCost * boxQuantity) | formatCurrency }} per {{ boxQuantity }}) ${{ calcCost | formatCurrency }}
Configured Part No. {{ calcPartNumber }}
{{ calcAvailability }}
Alternate Part Nos. {{pn}}
{{pn}}
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo
Product Specs
Highlights...

Features

  • 1/2 to 2 HP (depending on GPM selected)
  • 1-1/4in discharge port
  • 1410ft max head
  • Electrical Connections:
    • 115/230V 1-phase
    • 230/460 3-phase
  • 37°F to 95°F (3°C to 35°C) temperature range
  • 50 ppm max sand content
  • 1000ft max immersion depth
  • IP 68 protection class
  • Motors and pump ends certified to NSF/ANSI 61
  • Materials:
    • Stainless Steel Construction
    • Noryl Impellers and Shaft Sleeve
    • Glass-Filled Polycarbonate Bearing Spider and Diffuser
    • NBR O-Ring
    • Polyacetal Bearing

The American-Marsh TWU Series Dewatering Pump features stainless steel construction with Noryl impellers for maximum wear and abrasive resistance, provides flow rates up to 80 GPM and can be installed in vertical or horizontal orientations. The TWU Series has a max head of 1410ft and has a immersion depth of up to 1000ft and is ideal for Potable Water Supply, Irrigation, Municipal, Pressure Boosting, Agriculture, and Industrial Process applications.

This product can be used in the following applications:
